Data Insights Agent Blueprint

You are a data scientist performing exploratory data analysis. Your job is to
load a dataset, analyze it comprehensively, and produce actionable insights.
Follow this protocol:

1. THOUGHT: What type of data is this? What patterns should I look for?
2. ACTION: Load the dataset, compute descriptive statistics
3. Find correlations between numeric variables
4. Detect outliers using IQR or z-score methods
5. Generate charts for the most important relationships
6. Write a plain-English insights report with specific recommendations
7. FINAL_REPORT: Summary + key findings + charts + recommendations

Rules:
- Always profile the dataset first (types, nulls, ranges) before analysis
- Focus on the user's stated question — don't produce generic analysis
- Charts must be labeled, legible, and saved to the output directory
- Use IQR (1.5x rule) for outlier detection unless the data is normally distributed
- Report correlation strength with context — 0.7 may be strong in social science but weak in physics
- Write insights that someone without a statistics background can act on

### Tool Definitions

<ParameterGrid title="Agent Tools" items={[
  { param: "load_dataset", description: "Load a CSV or JSON dataset. Returns shape, column list, dtypes, and first 5 rows.", values: "path?: string (default: config dataset_path)" },
  { param: "describe_statistics", description: "Compute descriptive statistics: mean, median, std, min, max, quartiles, skew, kurtosis for numeric columns. Also value counts for categorical columns.", values: "columns?: string[] (default: all)" },
  { param: "find_correlations", description: "Compute pairwise Pearson correlation for numeric columns. Returns top correlations sorted by absolute value.", values: "threshold?: float (default 0.3), columns?: string[]" },
  { param: "detect_outliers", description: "Detect outliers using the IQR method (1.5x). Returns rows and values that fall outside the fences.", values: "column: string, method?: 'iqr' | 'zscore'" },
  { param: "generate_chart", description: "Generate a chart (scatter, bar, histogram, box plot, heatmap) and save to the output directory. Returns the file path.", values: "chart_type: string, x_column: string, y_column?: string, title?: string" },
  { param: "write_report", description: "Generate a plain-English insights report from analysis results. Uses LLM to synthesize findings.", values: "analysis_json: string" }
]} />

### Tool Implementation

```python
# tools.py
import os
import json
import numpy as np
import pandas as pd
import matplotlib
matplotlib.use("Agg")  # non-interactive backend
import matplotlib.pyplot as plt

DATASET_PATH = None
OUTPUT_DIR = None
CHART_FORMAT = "png"
_df = None  # cached dataframe

def load_dataset(path=None):
    global _df
    path = path or DATASET_PATH
    full = path if os.path.isabs(path) else os.path.join(os.getcwd(), path)
    if not os.path.exists(full):
        return f"ERROR: Dataset not found: {path}"

    try:
        if path.endswith(".csv"):
            _df = pd.read_csv(full)
        elif path.endswith(".json") or path.endswith(".jsonl"):
            _df = pd.read_json(full, lines=path.endswith(".jsonl"))
        else:
            return f"ERROR: Unsupported file format: {path}"

        return (
            f"Loaded {path}\n"
            f"Shape: {_df.shape[0]} rows × {_df.shape[1]} columns\n"
            f"Columns: {list(_df.columns)}\n"
            f"Dtypes:\n{_df.dtypes.to_string()}\n\n"
            f"First 5 rows:\n{_df.head().to_string()}\n\n"
            f"Null counts:\n{_df.isnull().sum().to_string()}"
        )
    except Exception as e:
        return f"ERROR loading dataset: {e}"


def describe_statistics(columns=None):
    if _df is None:
        return "ERROR: No dataset loaded. Call load_dataset first."

    cols = columns or list(_df.columns)
    numeric = [c for c in cols if c in _df.columns and _df[c].dtype in ("int64", "float64")]
    categorical = [c for c in cols if c in _df.columns and c not in numeric]

    output = []

    if numeric:
        desc = _df[numeric].describe().T
        # Add skew and kurtosis
        desc["skew"] = _df[numeric].skew()
        desc["kurtosis"] = _df[numeric].kurtosis()
        output.append("=== NUMERIC COLUMNS ===")
        output.append(desc.to_string())

    if categorical:
        output.append("\n=== CATEGORICAL COLUMNS ===")
        for col in categorical[:10]:
            vc = _df[col].value_counts().head(10)
            output.append(f"\n{col} ({_df[col].nunique()} unique):")
            output.append(vc.to_string())

    return "\n".join(output)


def find_correlations(threshold=0.3, columns=None):
    if _df is None:
        return "ERROR: No dataset loaded."

    numeric = [c for c in (_df.select_dtypes(include=[np.number]).columns)
               if not columns or c in columns]

    if len(numeric) < 2:
        return "Need at least 2 numeric columns for correlation analysis."

    corr_matrix = _df[numeric].corr()
    pairs = []
    for i in range(len(numeric)):
        for j in range(i + 1, len(numeric)):
            val = corr_matrix.iloc[i, j]
            if abs(val) >= threshold:
                pairs.append({
                    "col_a": numeric[i], "col_b": numeric[j],
                    "correlation": round(val, 3),
                    "strength": "strong" if abs(val) > 0.7 else "moderate" if abs(val) > 0.4 else "weak"
                })

    pairs.sort(key=lambda x: abs(x["correlation"]), reverse=True)
    if not pairs:
        return f"No correlations found above threshold {threshold}."
    return json.dumps(pairs, indent=2)


def detect_outliers(column, method="iqr"):
    if _df is None:
        return "ERROR: No dataset loaded."
    if column not in _df.columns:
        return f"ERROR: Column '{column}' not found."
    if _df[column].dtype not in ("int64", "float64"):
        return f"ERROR: Column '{column}' is not numeric."

    data = _df[column].dropna()
    if method == "iqr":
        q1 = data.quantile(0.25)
        q3 = data.quantile(0.75)
        iqr = q3 - q1
        lower = q1 - 1.5 * iqr
        upper = q3 + 1.5 * iqr
        outliers = _df[(data < lower) | (data > upper)]
        method_name = f"IQR (Q1={q1:.2f}, Q3={q3:.2f}, IQR={iqr:.2f})"
        fences = f"lower={lower:.2f}, upper={upper:.2f}"
    elif method == "zscore":
        from scipy import stats
        z = np.abs(stats.zscore(data))
        outliers = _df[z > 3]
        method_name = "Z-score (threshold=3)"
        fences = f"> 3 standard deviations from mean"
    else:
        return f"Unknown method: {method}. Use 'iqr' or 'zscore'."

    return json.dumps({
        "column": column,
        "method": method_name,
        "fences": fences,
        "outlier_count": len(outliers),
        "outlier_pct": round(len(outliers) / len(_df) * 100, 2),
        "outlier_values": outliers[column].describe().to_dict()
    }, indent=2, default=str)


def generate_chart(chart_type, x_column, y_column=None, title=None):
    if _df is None:
        return "ERROR: No dataset loaded."
    if x_column not in _df.columns:
        return f"ERROR: Column '{x_column}' not found."

    os.makedirs(OUTPUT_DIR, exist_ok=True)
    filename = f"{chart_type}_{x_column}"
    if y_column:
        filename += f"_vs_{y_column}"
    filename += f".{CHART_FORMAT}"
    filepath = os.path.join(OUTPUT_DIR, filename)

    plt.figure(figsize=(10, 6))
    data = _df[[x_column] + ([y_column] if y_column and y_column in _df.columns else [])].dropna()

    if chart_type == "scatter" and y_column:
        plt.scatter(data[x_column], data[y_column], alpha=0.5, s=10)
        plt.xlabel(x_column)
        plt.ylabel(y_column)
    elif chart_type == "bar" and y_column:
        data.groupby(x_column)[y_column].mean().sort_values().tail(20).plot(kind="barh")
        plt.xlabel(y_column)
        plt.ylabel(x_column)
    elif chart_type == "histogram":
        plt.hist(data[x_column], bins=30, edgecolor="black", alpha=0.7)
        plt.xlabel(x_column)
        plt.ylabel("Frequency")
    elif chart_type == "box":
        plt.boxplot(data[x_column].dropna(), vert=False)
        plt.xlabel(x_column)
    elif chart_type == "heatmap" and y_column:
        pivot = pd.crosstab(data[x_column], data[y_column])
        plt.imshow(pivot, aspect="auto", cmap="YlOrRd")
        plt.colorbar(label="Count")
        plt.xticks(range(len(pivot.columns)), pivot.columns, rotation=45, ha="right")
        plt.yticks(range(len(pivot.index)), pivot.index)
    else:
        plt.close()
        return f"Unsupported chart type or missing columns: {chart_type}"

    if title:
        plt.title(title)
    plt.tight_layout()
    plt.savefig(filepath, dpi=150, bbox_inches="tight")
    plt.close()
    return f"Chart saved: {filepath}"


def write_report(client, model, analysis_json):
    prompt = f"""Write a data insights report based on this analysis. Use plain English
that someone without a statistics background can understand.

Analysis results:
{analysis_json}

Structure your report as:
1. Executive Summary (3-4 sentences — what's the dataset, key findings)
2. Key Findings (numbered list, each with the finding + what it means)
3. Top Correlations (what variables move together and why it matters)
4. Notable Outliers (how many, which variables, what to investigate)
5. Recommendations (3-5 specific, actionable next steps)

Keep it concise. Focus on actionable insights, not statistical jargon."""

    response = client.chat.completions.create(
        model=model,
        messages=[{"role": "user", "content": prompt}],
        temperature=0.2
    )
    return response.choices[0].message.content

# agent.py
import json
import argparse
from openai import OpenAI
import tools as agent_tools

TOOL_SCHEMAS = [
    {
        "type": "function",
        "function": {
            "name": "load_dataset",
            "description": "Load a CSV or JSON dataset and return shape, columns, dtypes, and preview",
            "parameters": {
                "type": "object",
                "properties": {"path": {"type": "string"}},
                "required": []
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "describe_statistics",
            "description": "Compute descriptive statistics for all or specified columns",
            "parameters": {
                "type": "object",
                "properties": {
                    "columns": {"type": "array", "items": {"type": "string"}}
                },
                "required": []
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "find_correlations",
            "description": "Find pairwise correlations between numeric columns above a threshold",
            "parameters": {
                "type": "object",
                "properties": {
                    "threshold": {"type": "number", "default": 0.3},
                    "columns": {"type": "array", "items": {"type": "string"}}
                },
                "required": []
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "detect_outliers",
            "description": "Detect outliers in a numeric column using IQR or z-score method",
            "parameters": {
                "type": "object",
                "properties": {
                    "column": {"type": "string"},
                    "method": {"type": "string", "enum": ["iqr", "zscore"]}
                },
                "required": ["column"]
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "generate_chart",
            "description": "Generate and save a chart (scatter, bar, histogram, box, heatmap)",
            "parameters": {
                "type": "object",
                "properties": {
                    "chart_type": {"type": "string", "enum": ["scatter", "bar", "histogram", "box", "heatmap"]},
                    "x_column": {"type": "string"},
                    "y_column": {"type": "string"},
                    "title": {"type": "string"}
                },
                "required": ["chart_type", "x_column"]
            }
        }
    },
    {
        "type": "function",
        "function": {
            "name": "write_report",
            "description": "Generate a plain-English insights report from analysis results",
            "parameters": {
                "type": "object",
                "properties": {"analysis_json": {"type": "string"}},
                "required": ["analysis_json"]
            }
        }
    }
]

SYSTEM_PROMPT = """You are a data scientist performing exploratory data analysis.
Your job is to load a dataset, analyze it comprehensively, and produce actionable
insights. Follow this protocol:

1. THOUGHT: What type of data is this? What patterns should I look for?
2. ACTION: Load the dataset, compute descriptive statistics
3. Find correlations between numeric variables
4. Detect outliers using IQR or z-score methods
5. Generate charts for the most important relationships
6. Write a plain-English insights report with specific recommendations
7. FINAL_REPORT: Summary + key findings + charts + recommendations

Rules:
- Always profile the dataset first (types, nulls, ranges) before analysis
- Focus on the user's stated question — don't produce generic analysis
- Charts must be labeled, legible, and saved to the output directory
- Use IQR (1.5x rule) for outlier detection
- Report correlation strength with context
- Write insights that someone without a statistics background can act on"""


def run_agent(task: str, config: dict):
    client = OpenAI(api_key=config["openai_api_key"])
    model = config.get("model", "gpt-4o")

    agent_tools.DATASET_PATH = config.get("dataset_path", "./data.csv")
    agent_tools.OUTPUT_DIR = config.get("output_directory", "./insights")
    agent_tools.CHART_FORMAT = config.get("chart_format", "png")

    os.makedirs(agent_tools.OUTPUT_DIR, exist_ok=True)

    messages = [
        {"role": "system", "content": SYSTEM_PROMPT},
        {"role": "user", "content": f"Analyze this dataset. Task: {task}"}
    ]

    for i in range(config.get("max_iterations", 8)):
        response = client.chat.completions.create(
            model=model,
            messages=messages,
            tools=TOOL_SCHEMAS,
            temperature=0.1
        )

        msg = response.choices[0].message
        messages.append(msg)

        if msg.content and "FINAL_REPORT:" in msg.content:
            return msg.content.split("FINAL_REPORT:", 1)[1].strip()

        if not msg.tool_calls:
            messages.append({
                "role": "user",
                "content": "Continue the analysis. Load data, compute stats, find correlations, detect outliers, generate charts, and provide FINAL_REPORT."
            })
            continue

        for tool_call in msg.tool_calls:
            func_name = tool_call.function.name
            func_args = json.loads(tool_call.function.arguments)

            if func_name == "load_dataset":
                result = agent_tools.load_dataset(func_args.get("path"))
            elif func_name == "describe_statistics":
                result = agent_tools.describe_statistics(func_args.get("columns"))
            elif func_name == "find_correlations":
                result = agent_tools.find_correlations(
                    func_args.get("threshold", 0.3),
                    func_args.get("columns"))
            elif func_name == "detect_outliers":
                result = agent_tools.detect_outliers(
                    func_args.get("column", ""),
                    func_args.get("method", "iqr"))
            elif func_name == "generate_chart":
                result = agent_tools.generate_chart(
                    func_args.get("chart_type", ""),
                    func_args.get("x_column", ""),
                    func_args.get("y_column"),
                    func_args.get("title"))
            elif func_name == "write_report":
                result = agent_tools.write_report(
                    client, model,
                    func_args.get("analysis_json", ""))
            else:
                result = f"Unknown tool: {func_name}"

            messages.append({
                "role": "tool",
                "tool_call_id": tool_call.id,
                "content": result
            })

    return "Agent reached max iterations."


if __name__ == "__main__":
    parser = argparse.ArgumentParser()
    parser.add_argument("--task", required=True, help="Analysis task description")
    parser.add_argument("--config", default="config.json")
    args = parser.parse_args()

    with open(args.config) as f:
        config = json.load(f)

    result = run_agent(args.task, config)
    print(result)
    print(f"\nCharts saved to: {config.get('output_directory', './insights')}")
